AcquCAM 23G

AcquCAM 23G

(Down load Catalog ACQUCAM 23G)

  • USB 3.0 Color Camera
  • 1/1.2 ” Exmor Sensor
  • 1920×1200 pixel
  • Trigger input and I/O

AcquCAM 23G

The displays live digital images with gradual smoothness and combines exceptional resolution  with faithful color reproduction.The new sensors feature a global shutter function and able to capture a high-speed moving image without focal plane distortion. High-speed processing, low noise and low power dissipation by using column-parallel A/D conversion. equipped with trigger mode, and the external pulse can control accumulation time. The Sensor also have a pulse output function to indicate respective conditions during shutter operation and can be coordinated with peripheral circuits. High-definition images can be displayed live at a rate of high frames per second. without compression. Such imaging quality enables even the finest cellular regions to be observed clearly and distinctly without deterioration. While focusing is made stress free.

Universal camera- wide range of image acquisition  is available

Setting function of variety color images

AcquCAM23_16
With wide range of color temperature setting function, you can obtain a clear image of high sensitivity in accordance with the characteristics of samples you want to observe.



Live sharpness adjustment

You can observe and obtain sharp images by applying the sharpness function even when the live video output
You can observe and obtain sharp images by applying the sharpness function even when the live video output





[Specification]
Spec Description
Size 1/1.2 inch
Resolution H: 1920, V: 1200
Pixel size H: 5.86 µm, V: 5.86 µm
Video formats

& Frame rate

 1920×1200 RGB32 @ 54 fps

1920×1200 Y16 @ 25 fps

1920×1200 Y800 @ 54 fps
Dynamic range 8 / 12 bit
Exposure time 1/100000 to 30 s
Lens mount C/Cs mount
Interface USB 3.0
Power supply 4.5 to 5.5 VDC
Dimensions H: 29 mm, W: 29 mm, L: 43 mm
Mass

65 g
